H-M Model “P”

Introducing the Alpha H-M Bridge Plug Model “P”: engineered to withstand high pressure and temperature conditions with ease. This plug revolutionizes the setting process, utilizing hydraulic power to engage the top slips and then employing mechanical pull to finalize the set. Unlike traditional methods, there’s no need for a separate mechanical setting tool as the mechanism is integrated within the plug itself.

Setting the plug is straightforward: a ball is inserted into the tubing string, blocking the built-in equalizing ports. Pressure is then applied to activate the top slip, followed by mechanical pull to secure the set. Releasing the tubing string from the plug with right hand rotation.

After release, the full tubing I.D. is restored, allowing seamless extension of other equipment through the tubing string’s end. Experience unparalleled efficiency and reliability with the Alpha H-M Bridge Plug Model “P”.

Tubing/Casing OD: 3 1/2″ – 20″

Max Pressure: 10K

Running Guidelines
Download Brochure

FEATURES

  • Drillable cast iron construction
  • Sets in any grade casing including P-110
  • Metal back-up to prevent rubber extrusion
  • For permanent service
  • Ratcheting lock ring holds setting force
  • Excellent for deviated wells
  • Can be upgraded to 400F temperature rating upon request

H-M Model “E”

When high pressure and high temperature are not a factor, the Alpha H-M Bridge Plug Model “E” is more specifically engineered to withstand moderate temperature and moderate pressure conditions with ease. This plug streamlines the setting process, utilizing hydraulic power to engage the top slips and then employing mechanical pull to finalize the set. Unlike traditional methods, there’s no need for a separate mechanical setting tool as the mechanism is integrated within the plug itself.

Setting the plug is straightforward: a ball is inserted into the tubing string, blocking the built-in equalizing ports. Pressure is then applied to activate the top slip, followed by mechanical pull to secure the set. Releasing the tubing string from the plug with right hand rotation.

After release, the full tubing I.D. is restored, allowing seamless extension of other equipment through the tubing string’s end. Experience unmatched efficiency and reliability with the Alpha H-M Bridge Plug Model “E”.

Tubing/Casing OD: 4 1/2″ – 7″

Max Pressure: 6K

Running Guidelines
Download Brochure

FEATURES

  • Drillable cast iron construction
  • Sets in any grade casing including P-110
  • Metal back-up to prevent rubber extrusion
  • For permanent service
  • Ratcheting lock ring holds setting force
  • Excellent for deviated wells
  • Can be upgraded to 400F temperature rating upon request

MagnaBore™

Introducing the MagnaBore™ HM Bridge Plug from Alpha Oil Tools: a revolutionary solution designed for high-profile well environments, enabling seamless single trip abandonment and cementing operations. With its advanced hydromechanical set mechanism, the MagnaBore™ offers unparalleled reliability and efficiency.

Thanks to its unique and enlarged flow area design, fluid circulation above the plug is facilitated at any time before setting, providing exceptional flexibility in well operations. Experience the efficiency and reliability of the MagnaBore™ HM Bridge Plug for your well operations.

Tubing/Casing OD: 7″ – 20″

Max Pressure: 10K

Play Video

Watch Magna Bore Video

Running Guidelines
Download Brochure

FEATURES:

  • Enlarged flow area design
  • Drillable cast iron construction
  • Sets in any grade casing including P-110
  • Form-fitting metal back-ups prevent rubber extrusion
  • For permanent service
  • Ratcheting lock ring holds setting force
  • Can be upgraded to 400F temperature rating upon request

Maverick™ H-M

Introducing the Maverick™ Bridge Plug: a specialized plug that has gained widespread acclaim in Canada for its versatility reminiscent of HM-1 tool set plugs from the past. Available in both 10k (Maverick™-10) and 6k (Maverick™-6) maximum pressure ratings, the Maverick™ is engineered to meet the diverse needs of modern applications. Experience the reliability and adaptability of the Maverick™ Bridge Plug for your operations.

The Maverick™ Bridge Plug is manufactured with drillable materials for rapid drill out.

Tubing/Casing OD: 4 1/2″ – 7″

Max Pressure: 10K

Setting Tool: Weatherford HM-1B or CD HMII

Running Guidelines
Download Brochure

FEATURES

  • Drillable cast iron construction
  • Sets in any grade casing including P-110
  • Form-fitting metal back-ups prevent rubber extrusion
  • For permanent service
  • Ratcheting lock ring holds setting force
  • Can be upgraded to 400F temperature rating upon request
